Wholesale Din1478 M30 Galvanized Eye Eye Turnbuckle Rigging Screw

Home / Products / Turnbuckle Assembly / Din1478 M30 Galvanized Eye Eye Turnbuckle Rigging Screw

How Can We Help You ?

We will reply you within 24 hours in working day.

+86-13486669457 Contact Us
  • Din1478 M30 Galvanized Eye Eye Turnbuckle Rigging Screw

Din1478 M30 Galvanized Eye Eye Turnbuckle Rigging Screw

  • Din1478 M30 Galvanized Eye Eye Turnbuckle Rigging Screw
Inquiry
DIN1478 M30 Galvanized Eye-Eye Turnbuckle Rigging Screw is a type of fastening equipment used in rigging and lifting applications. It consists of two threaded eye bolts interlinked by a threaded rod with a central body, allowing for the adjustment of tension in a system.The turnbuckle is galvanized, which means it has been coated with a layer of zinc to protect against corrosion. This makes it suitable for use in outdoor and marine environments, where exposure to moisture and other elements is common. The eye-eye configuration of the turnbuckle means that it features two eye bolts at each end, allowing for easy attachment to rigging components such as cables, ropes, or chains. The threaded rod in the center can be rotated to either shorten or lengthen the distance between the eye bolts, providing a convenient means of adjusting tension in a system.
PREV：No previous article
NEXT：Tractor Forged Top Link Turnbuckle For Three Point Linkage
  • Description
  • Inquiry

  • Product:

     Din1478 M30 Galvanized Eye Eye Turnbuckle Rigging Screw

    Material:

     DIN 1478,carbon steel&stainless steel

    Finish:

     hot dip galvanization, self-color, electroplating white Zinc,Polished

    Type:

     hook & hook, eye & eye, jaw & jaw, hook & eye, jaw & eye, stub & stub end turnbuckles

    Size:

     M6-M48

    Use:

     Rigging screw

    Product range:

     Series of rigging screws; adjustable leveling assembly (stabilizer) and ratchet jack ( lifting arm), stabilizer chains assembly, top link assembly(upper link arm), lower link arm, ball joint terminals, ball and bushes, cross bar, top hooks, ball tie-rods and swiveling tie rods, turnbuckles, etc.

    turnbuckles

    Din1478 with

    Eye&Eye

    Dimension

    s in mm











    Gewinde Thread

    A

    D

    H

    F

    J

    Weight kg/100

    piece

    M6

    110

    6

    50

    74

    10

    16

    M8

    110

    8

    52

    80

    11

    18

    M10

    125

    8

    59

    95

    15

    28

    M12

    125

    10

    66

    107

    17

    42

    M16

    170

    10

    85

    146

    22

    91

    M20

    200

    12

    100

    170

    24

    136

    M24

    255

    12

    134

    213

    33

    260

    M30

    255

    16

    150

    255

    39

    375

    M36

    295

    16

    150

    260

    37

    635

    M42

    330

    20

    165

    285

    48

    1050

    M48

    355

    20

    185

    335

    58

    1550


    turnbuckles

    Din1478 with

    Hook&Hook

    Dimensions in mm

    Gewinde Thread

    A

    D

    H



    K

    Weight kg/100

    piece

    M6

    110

    6

    50

    77

    9.5

    16

    M8

    110

    8

    60

    98

    11

    20

    M10

    125

    8

    73

    116.5

    14

    30

    M12

    125

    10

    90

    146

    18

    47

    M16

    170

    10

    100

    165

    19

    101

    M20

    200

    12

    105

    180

    21

    140

    M24

    255

    12

    135

    225

    29

    286

    M30

    255

    16

    140

    255

    31

    409

    M36

    295

    16

    170

    300

    35

    685

    M42

    330

    20

    165

    285

    48

    1050

    M48

    355

    20

    185

    335

    58

    1550


    TURNBUCKLES

    DIN 1478

    JAW&JAW























    Wll

    Breakin g load

    d1

    d4

    d5

    f

    g

    L1

    L3

    L4

    adjustab e

    weight  per 100

    Pcs

    Units per bag

    t

    BF

    min.KN

    mm

    mm

    mm

    mm

    mm

    mm

    mm

    mm

    mm

    kg



    0.25

    10

    M8

    8

    M6×35

    25

    9

    110

    101

    68

    85

    26

    1

    0.3

    12

    M10

    8

    M8×40

    29

    10.7

    125

    122

    82

    90

    45

    1

    0.6

    24

    M12

    10

    M10×50

    35

    15.5

    125

    151

    90

    90

    66

    1

    1.5

    70

    M16



    M16

    46

    20

    170

    175

    102

    110

    158

    1

    3

    135

    M20



    M20

    61

    29

    200

    205

    115

    130

    302

    1

    5.5

    250

    M24



    M24

    71

    34

    255

    255

    125

    160

    509

    1

    8

    360

    M30



    M30

    95

    44

    255

    300

    150

    180

    982

    1
